Tech Specs
Motor Horsepower | 1-3/4 HP TEFC |
Motor Amps | 14/7 |
Motor Volts | 115/230V, 60Hz, 1Ph |
Blade Speed | 1,445/2,950 FT/MIN |
Cutting Capacity Height | 13” |
Cutting Capacity Width | 13-5/8” |
Blade Width | 3/16” – 3/4” |
Blade Length | 111” |
Table Size | 21-1/2” x 15-3/4” |
Table Left Tilt | -7° |
Table Right Tilt | 45° |
Table Miter Gauge "T" Slot | (2) 3/4” x 3/8” |
Table Height to Floor | 40-1/2” |
Table Height to Base | 20-7/8” |
Table Fence Size | 18-3/4” x 1-3/4” x 6” |
Wheel Material | Cast Iron |
Blade Guide Type | Spring Loaded |
Table Trunnion | Cast Iron |
Overall Height | 74-1/2” |
Overall Width | 33-3/4” |
Overall Depth | 25” |
Overall Base Size | 24” x 17-5/8” |
Dust Port | 1@4” |
Overall Net Weight | 285 lbs. |
Warranty | 5 Years |
