10-1414: 14” Deluxe Bandsaw

SKU: 10-1414 Category:

STANDARD FEATURES

  • NEW 14” Resaw capacity
  • NEW SP Coated Table
  • NEW Quick Adjust Drift Fence
  • NEW Blade Tension System
  • NEW Blade Guard w/Magnetic Door
  • NEW 2-1/2” & 4” Dust Ports
  • UPDATED Storage Cabinet
  • FASTER SPEEDS – 1,476 / 3,280 ft/min
  • Quick-release blade tension system
  • Large blade tension hand wheel
  • Spring loaded tool-less blade guides
  • Lower wheel dust cleaning brush

14” BANDSAW 10-1414 has many NEW features that woodworkers will enjoy – including NEW SP Coated Table for corrosion protection and reduced friction, NEW Quick Adjust Drift 6” Tall Fence System with Micro-Adustment, NEW enhanced Blade Tension System with quick release blade tension lever, INCREASED 14” Cutting Capacity under the spring-loaded tool-less blade guides, and Two Dust ports. Plus NEW hinged safety Blade Guard with Magnetic Closure and UPDATED Storage Cabinet base. Its dual voltage, 1-3/4 HP motor provides ample power for most every
work encountered. Designed with two NEW speed options – 1,476 / 3,280 ft/min.

Tech Specs

Motor Horsepower1-3/4 HP TEFC
Motor Amps14/7
Motor Volts115/230V, 60Hz, 1Ph
Blade Speed1,476 / 3,280 ft/min
Cutting Capacity Height14”
Cutting Capacity Width13-5/8”
Blade Width3/16” – 3/4”
Blade Length111”
Table Size21-1/2” x 15-3/4”
Table Left Tilt-7°
Table Right Tilt45°
Table Miter Gauge "T" Slot(2) 3/4” x 3/8”
Table Height to Floor40-1/2”
Table Height to Base20-7/8”
Table Fence Size18-3/4” x 1-7/8” x 6”
Wheel MaterialCast Iron
Blade Guide TypeSpring Loaded
Table TrunnionCast Iron
Overall Height76”
Overall Width33-3/4”
Overall Depth25”
Overall Base Size24” x 17-5/8”
Dust Port1 @ 2-1/2” & 1 @ 4”
Overall Net Weight303.6 lbs.
WarrantyLifetime

Manuals

Download manual (English)Download manual (Spanish)Download manual (French)

Sell Sheets

Download sell sheet (English)

Parts List

View diagram
P10-1414-10A Locking handle $2.99 Out of Stock Add to cart
P10-1414-10B Retaining ring 12 $0.99 Out of Stock Add to cart
P10-1414-10C Flat washer 12 $0.99 Out of Stock Add to cart
P10-1414-10D Flat washer 10 $0.99 Out of Stock Add to cart
P10-1414-10E Hex socket head screw M5x12 $0.99 Out of Stock Add to cart
P10-1414-10F Flat washer 6 $0.99 Out of Stock Add to cart
P10-1414-10G Nylon washer $0.99 Out of Stock Add to cart
P10-1414-11A Flat washer 10 $0.99 Out of Stock Add to cart
P10-1414-11B Retaining ring 28 $0.99 Out of Stock Add to cart
P10-1414-11C Rivet 2D5x5 $0.99 Out of Stock Add to cart
P10-1414-11D Upper support plate $28.99 Out of Stock Add to cart
P10-1414-11E Washer 5 $0.99 Out of Stock Add to cart
P10-1414-11F Spacer bushing $0.99 Out of Stock Add to cart
P10-1414-11G Hex locking nut M6 $0.99 Out of Stock Add to cart
P10-1414-12A Hex Nut M10 $0.99 Out of Stock Add to cart
P10-1414-12B Tension wheel $5.99 Out of Stock Add to cart
P10-1414-12C Angle scale label $1.99 Out of Stock Add to cart
P10-1414-12D Support bracket $7.99 Out of Stock Add to cart
P10-1414-12E Connecting board $3.99 Out of Stock Add to cart
P10-1414-12F Rip fence $76.99 Out of Stock Add to cart
P10-1414-12G Door panel $32.99 Out of Stock Add to cart
P10-1414-13A Wing nut $1.99 Out of Stock Add to cart
P10-1414-13B Bearing $1.99 Out of Stock Add to cart
P10-1414-13C Hex countersunk head screw M8x16 $0.99 Out of Stock Add to cart
P10-1414-13D Cap nut M12 $0.99 Out of Stock Add to cart
P10-1414-13E Cross countersunk head screw M5x8 $0.99 Out of Stock Add to cart
P10-1414-13F Nylon plate $0.99 Out of Stock Add to cart
P10-1414-13G Door latch $7.99 Out of Stock Add to cart
P10-1414-14A Bolt shaft $3.99 Out of Stock Add to cart
P10-1414-14B Tension shaft $5.99 Out of Stock Add to cart
P10-1414-14C Rack $13.99 Out of Stock Add to cart
P10-1414-14D Spring washer 12 $0.99 Out of Stock Add to cart
P10-1414-14E Rack $10.99 Out of Stock Add to cart
P10-1414-14F Re-saw bar $15.99 Out of Stock Add to cart
P10-1414-15A Socket $1.99 Out of Stock Add to cart
P10-1414-15B Tension rod $6.99 Out of Stock Add to cart
P10-1414-15C Small handle $3.99 Out of Stock Add to cart
P10-1414-15D Flat washer 10 $0.99 Out of Stock Add to cart
P10-1414-15E Guide post $22.99 Out of Stock Add to cart
P10-1414-15F Stud bolt $1.99 Out of Stock Add to cart
P10-1414-16A Clear window $1.99 Out of Stock Add to cart
P10-1414-16B Set collar $0.99 Out of Stock Add to cart
P10-1414-16C Crank handwheel $9.99 Out of Stock Add to cart
P10-1414-16D Hex locking nut M10 $0.99 Out of Stock Add to cart
P10-1414-16E Cross pan head screwM5x8 $0.99 Out of Stock Add to cart
P10-1414-16F Bolt $1.99 Out of Stock Add to cart
P10-1414-17A Hex socket head screw M6x25 $0.99 Out of Stock Add to cart
P10-1414-17B Seting screw M5x8 $0.99 Out of Stock Add to cart
P10-1414-17C Hex set screw M6x12 $0.99 Out of Stock Add to cart
P10-1414-17D Pin 5x24 $0.99 Out of Stock Add to cart
P10-1414-17E Worm $6.99 Out of Stock Add to cart
P10-1414-17F Hex nut M10 $0.99 Out of Stock Add to cart
P10-1414-18A Star knob $1.99 Out of Stock Add to cart
P10-1414-18B Hex flat end set screw M6x8 $0.99 Out of Stock Add to cart
P10-1414-18C Gear shaft $22.99 Out of Stock Add to cart
P10-1414-18D Sliding seat $28.99 Out of Stock Add to cart
P10-1414-18E Gear bracket $20.99 Out of Stock Add to cart
P10-1414-18F Flat washer 10 $0.99 Out of Stock Add to cart
P10-1414-19A Hex locking nut M6 $0.99 Out of Stock Add to cart
P10-1414-19B Crank handwheel $7.99 Out of Stock Add to cart
P10-1414-19C Table trunnion $54.99 Out of Stock Add to cart
P10-1414-19D Sliding rod $8.99 Out of Stock Add to cart
P10-1414-19E Washer 6 $0.99 Out of Stock Add to cart
P10-1414-19F Connecting rod $2.99 Out of Stock Add to cart
P10-1414-1A Hex socket head screw M6x30 $0.99 Out of Stock Add to cart
P10-1414-1B Hex socket head screw M8x16 $0.99 Out of Stock Add to cart
P10-1414-1C Table with SPC Coating $329.99 Out of Stock Add to cart
P10-1414-1D Blade tension handwheel $5.99 Out of Stock Add to cart
P10-1414-1E Clear window $0.99 In Stock Add to cart
P10-1414-1F Locking handle $2.99 Out of Stock Add to cart
P10-1414-1G Rivet nut $0.99 Out of Stock Add to cart
P10-1414-20A Stud shaft $0.99 Out of Stock Add to cart
P10-1414-20B Small handle $3.99 Out of Stock Add to cart
P10-1414-20C Washer 8 $0.99 Out of Stock Add to cart
P10-1414-20D Washer 6 $0.99 Out of Stock Add to cart
P10-1414-20E Hex bolt M6x16 $0.99 Out of Stock Add to cart
P10-1414-20F Front guide rail $44.99 Out of Stock Add to cart
P10-1414-21A Table angle stop block $3.99 Out of Stock Add to cart
P10-1414-21B Lower wheel shaft $8.99 Out of Stock Add to cart
P10-1414-21C Spring washer 8 $0.99 Out of Stock Add to cart
P10-1414-21D Hex bolt M6x12 $0.99 Out of Stock Add to cart
P10-1414-21E Locking handle $1.99 Out of Stock Add to cart
P10-1414-21F Hex locking nut M8 $0.99 Out of Stock Add to cart
P10-1414-22A Flat washer 8 $0.99 Out of Stock Add to cart
P10-1414-22B Hex Nut $0.99 Out of Stock Add to cart
P10-1414-22C Hex socket head screw M8x25 $0.99 Out of Stock Add to cart
P10-1414-22D Lower support plate $7.99 Out of Stock Add to cart
P10-1414-22E Plate $0.99 Out of Stock Add to cart
P10-1414-22F Flat washer 8 $0.99 Out of Stock Add to cart
P10-1414-23A Self-locking nut M8 $0.99 Out of Stock Add to cart
P10-1414-23B Retaining ring 17 $0.99 Out of Stock Add to cart
P10-1414-23C Hex flat end set screw M6x12 $0.99 Out of Stock Add to cart
P10-1414-23D Flat washer 8 $0.99 Out of Stock Add to cart
P10-1414-23E Bushing $1.99 Out of Stock Add to cart
P10-1414-23F Hinge axis $3.99 Out of Stock Add to cart
P10-1414-24A Hex socket head screw M6x16 $0.99 Out of Stock Add to cart
P10-1414-24B Multi-vee belt (USE C10-995) $4.99 Out of Stock Add to cart
P10-1414-24C Cross recess pan head screw M3x5 $0.99 Out of Stock Add to cart
P10-1414-24D Spring washer 8 $0.99 Out of Stock Add to cart
P10-1414-24E Set collar $0.99 Out of Stock Add to cart
P10-1414-24F Locking handle $5.99 Out of Stock Add to cart
P10-1414-25A Flat washer 6 $0.99 Out of Stock Add to cart
P10-1414-25B Lower wheel $112.99 Out of Stock Add to cart
P10-1414-25C Pointer $1.99 Out of Stock Add to cart
P10-1414-25D Hex socket head screw M8x25 $0.99 Out of Stock Add to cart
P10-1414-25E Set screw M5x8 $0.99 Out of Stock Add to cart
P10-1414-25F Locking handle $3.99 Out of Stock Add to cart
P10-1414-26A Lower guide shield $0.99 Out of Stock Add to cart
P10-1414-26C Hex socket head screw M6x16 $0.99 Out of Stock Add to cart
P10-1414-26D Hex flat head screw M5x12 $0.99 Out of Stock Add to cart
P10-1414-26E Hex flat set screw M6x8 $0.99 Out of Stock Add to cart
P10-1414-26F Barrier bracket $30.99 Out of Stock Add to cart
P10-1414-27A Hex bolt M8x25 $0.99 Out of Stock Add to cart
P10-1414-27C Eccentric bushing $1.99 Out of Stock Add to cart
P10-1414-27D Pointer $0.99 Out of Stock Add to cart
P10-1414-27E Crank handwheel $7.99 Out of Stock Add to cart
P10-1414-27F Hex countersunk head screw M6x16 $0.99 Out of Stock Add to cart
P10-1414-28A Hex Nut M8 $0.99 Out of Stock Add to cart
P10-1414-28C Trunnion support $45.99 Out of Stock Add to cart
P10-1414-28D Screw $0.99 Out of Stock Add to cart
P10-1414-28E Small handle $3.99 Out of Stock Add to cart
P10-1414-28F Plate $4.99 Out of Stock Add to cart
P10-1414-29A Strain relief plate $2.99 Out of Stock Add to cart
P10-1414-29C Hex nut M10 $0.99 Out of Stock Add to cart
P10-1414-29D Hex nut M5 $0.99 Out of Stock Add to cart
P10-1414-29E Hex socket head screw M5x25 $0.99 Out of Stock Add to cart
P10-1414-29F Micro-adjust brackt $11.99 Out of Stock Add to cart
P10-1414-2A Push stick $3.99 Out of Stock Add to cart
P10-1414-2B Spring washer 8 $0.99 Out of Stock Add to cart
P10-1414-2C Table insert (USE C10-391) $1.99 Out of Stock Add to cart
P10-1414-2D Blade tension rod $12.99 Out of Stock Add to cart
P10-1414-2E Guide cover $6.90 Out of Stock Add to cart
P10-1414-2F Washer 8 $0.99 Out of Stock Add to cart
P10-1414-2G Left side panel $39.99 Out of Stock Add to cart
P10-1414-30A Strain relief M20 $3.99 Out of Stock Add to cart
P10-1414-30C Washer 10 $0.99 Out of Stock Add to cart
P10-1414-30D Sliding plate $8.99 Out of Stock Add to cart
P10-1414-30E Ratchet handle $3.99 Out of Stock Add to cart
P10-1414-30F Micro-adjust handle shaft $1.99 Out of Stock Add to cart
P10-1414-31A Hex flat head screw M6x10 $0.99 Out of Stock Add to cart
P10-1414-31C Block $5.99 Out of Stock Add to cart
P10-1414-31D Spring $4.99 Out of Stock Add to cart
P10-1414-31E Rear guide shaft $7.99 Out of Stock Add to cart
P10-1414-31F Round gasket $0.99 Out of Stock Add to cart
P10-1414-32A Hex set screw M6x8 $0.99 Out of Stock Add to cart
P10-1414-32C Eccentric handle $25.99 Out of Stock Add to cart
P10-1414-32D Upper wheel shaft $6.99 Out of Stock Add to cart
P10-1414-32E Upper guide support block $6.99 Out of Stock Add to cart
P10-1414-32F Locking knob $4.99 Out of Stock Add to cart
P10-1414-33A Motor pulley $9.99 Out of Stock Add to cart
P10-1414-33C Knob $1.99 Out of Stock Add to cart
P10-1414-33D Knob $1.99 Out of Stock Add to cart
P10-1414-33E Upper guide support rod $4.99 Out of Stock Add to cart
P10-1414-33F Hex socket head screw M4x12 $0.99 Out of Stock Add to cart
P10-1414-34A Motor $299.99 Out of Stock Add to cart
P10-1414-34C Tensioning sleeve $7.99 Out of Stock Add to cart
P10-1414-34E Spring $0.99 Out of Stock Add to cart
P10-1414-35A Dust port $3.99 Out of Stock Add to cart
P10-1414-35C Bushing $1.99 Out of Stock Add to cart
P10-1414-35E Guide shaft $5.99 Out of Stock Add to cart
P10-1414-36A Hex flange nut M8 $0.99 Out of Stock Add to cart
P10-1414-36C Hex flat head screw M8x12 $0.99 Out of Stock Add to cart
P10-1414-36E Bushing $1.99 Out of Stock Add to cart
P10-1414-37A Fixed bracket $4.99 Out of Stock Add to cart
P10-1414-37C Flat washer 10 $0.99 Out of Stock Add to cart
P10-1414-37E Bearing $2.99 Out of Stock Add to cart
P10-1414-38A Hex socket head screw M8x20 $0.99 Out of Stock Add to cart
P10-1414-38C Spring washer 10 $0.99 Out of Stock Add to cart
P10-1414-38E Washer 8 $0.99 Out of Stock Add to cart
P10-1414-39A Hex bolt M8x20 $0.99 Out of Stock Add to cart
P10-1414-39C Hex bolt M10x25 $0.99 Out of Stock Add to cart
P10-1414-39E Locking handle $1.99 Out of Stock Add to cart
P10-1414-3A Hex Nut M6 $0.99 Out of Stock Add to cart
P10-1414-3B Hex Nut M6 $0.99 Out of Stock Add to cart
P10-1414-3C Hex flat set screw $0.99 Out of Stock Add to cart
P10-1414-3D Flat washer 12 $0.99 Out of Stock Add to cart
P10-1414-3E Hex flat head screw M6x10 $0.99 Out of Stock Add to cart
P10-1414-3F Spring $0.99 Out of Stock Add to cart
P10-1414-3G Upper door hinge $1.99 Out of Stock Add to cart
P10-1414-40A Hex socket head screw M6x45 $0.99 Out of Stock Add to cart
P10-1414-40E Flat washer 5 $0.99 Out of Stock Add to cart
P10-1414-41A Flat washer 6 $0.99 Out of Stock Add to cart
P10-1414-41E Connecting plate $1.99 Out of Stock Add to cart
P10-1414-42A Dust port $2.99 Out of Stock Add to cart
P10-1414-42E Lower guide block $35.99 Out of Stock Add to cart
P10-1414-43A Cross pan head screw M4x5 $0.99 Out of Stock Add to cart
P10-1414-43E Spring $0.99 Out of Stock Add to cart
P10-1414-44A Clear window $0.99 Out of Stock Add to cart
P10-1414-44E Guide shaft $7.90 Out of Stock Add to cart
P10-1414-45A Hex bolt and Spring washer assembly $0.99 Out of Stock Add to cart
P10-1414-45E Flat washer 6 $0.99 Out of Stock Add to cart
P10-1414-46A Big washer 6 $0.99 Out of Stock Add to cart
P10-1414-46E Ratchet handle $1.99 Out of Stock Add to cart
P10-1414-47A Dust removal plate $3.99 Out of Stock Add to cart
P10-1414-47E Hex flat end set screw M6x10 $0.99 Out of Stock Add to cart
P10-1414-48A Brush $1.99 Out of Stock Add to cart
P10-1414-48E Upper guide block $31.99 Out of Stock Add to cart
P10-1414-49A Hex bolt M6x25 $0.99 Out of Stock Add to cart
P10-1414-49E Hex flat end set screw M8x10 $0.99 Out of Stock Add to cart
P10-1414-4A Frame $499.99 Out of Stock Add to cart
P10-1414-4B Retaining ring 40 $0.99 Out of Stock Add to cart
P10-1414-4C Table alignment pin $4.99 Out of Stock Add to cart
P10-1414-4D Circlips 6 $0.99 Out of Stock Add to cart
P10-1414-4E Hex countersunk head screw M4x16 $0.99 Out of Stock Add to cart
P10-1414-4F Round handle $8.99 Out of Stock Add to cart
P10-1414-4G Back side panel $36.99 Out of Stock Add to cart
P10-1414-50A Hex Nut M5 $0.99 Out of Stock Add to cart
P10-1414-50E Locking handle $1.99 Out of Stock Add to cart
P10-1414-51A Flat washer 5 $0.99 Out of Stock Add to cart
P10-1414-51E Hex socket head screw M6x16 $0.99 Out of Stock Add to cart
P10-1414-52A Hex socket head screw M5x12 $0.99 Out of Stock Add to cart
P10-1414-52E Guide bracket cover $1.99 Out of Stock Add to cart
P10-1414-53A Cross pan head screw M4x10 $0.99 Out of Stock Add to cart
P10-1414-53E Bolt $1.99 Out of Stock Add to cart
P10-1414-54A Switch $31.99 Out of Stock Add to cart
P10-1414-54E Gear $3.99 Out of Stock Add to cart
P10-1414-55A Cross pan head screw M4x10 $0.99 Out of Stock Add to cart
P10-1414-55E Hex flat end set screw M6x12 $0.99 Out of Stock Add to cart
P10-1414-56A Flat washer 4 $0.99 Out of Stock Add to cart
P10-1414-57A Flat washer 4 $0.99 Out of Stock Add to cart
P10-1414-58A Blind rivets $0.99 Out of Stock Add to cart
P10-1414-59A Spring leaf $0.99 Out of Stock Add to cart
P10-1414-5A Cross pan head screw M4x12 $0.99 Out of Stock Add to cart
P10-1414-5B Bearing $2.99 Out of Stock Add to cart
P10-1414-5C Hex nut M4 $0.99 Out of Stock Add to cart
P10-1414-5D Upper slide block $5.99 Out of Stock Add to cart
P10-1414-5E Hinge shaft $1.99 Out of Stock Add to cart
P10-1414-5F Locking knob $1.99 Out of Stock Add to cart
P10-1414-5G Hex flange bolt M6x12 $0.99 Out of Stock Add to cart
P10-1414-60A Upper door $52.99 Out of Stock Add to cart
P10-1414-61A Clear window $1.99 Out of Stock Add to cart
P10-1414-62A Lower door $50.99 In Stock Add to cart
P10-1414-63A Bushing $0.99 Out of Stock Add to cart
P10-1414-64A Hex socket head screw M6x20 $0.99 Out of Stock Add to cart
P10-1414-6A Guide post cap $2.99 Out of Stock Add to cart
P10-1414-6B Tube $0.99 Out of Stock Add to cart
P10-1414-6C Magnet $3.99 Out of Stock Add to cart
P10-1414-6D Lower slide block $10.99 Out of Stock Add to cart
P10-1414-6E Magnet $1.99 Out of Stock Add to cart
P10-1414-6F Support arm $39.99 Out of Stock Add to cart
P10-1414-6G Shelf $22.99 Out of Stock Add to cart
P10-1414-7A Rubber cover $1.99 Out of Stock Add to cart
P10-1414-7B Upper wheel $86.99 Out of Stock Add to cart
P10-1414-7C Hex nut M8 $0.99 Out of Stock Add to cart
P10-1414-7D Flat washer 20 $0.99 Out of Stock Add to cart
P10-1414-7E Hex locking nut M4 $0.99 Out of Stock Add to cart
P10-1414-7F Pin 6x26 $0.99 Out of Stock Add to cart
P10-1414-7G Right side panel $39.99 Out of Stock Add to cart
P10-1414-8A Tool holder $0.99 Out of Stock Add to cart
P10-1414-8B Tire $5.99 Out of Stock Add to cart
P10-1414-8C Hex bolt M8x50 $0.99 Out of Stock Add to cart
P10-1414-8D Hex nut M10 $0.99 Out of Stock Add to cart
P10-1414-8E Guide shield $10.99 Out of Stock Add to cart
P10-1414-8F Locking plate $3.99 Out of Stock Add to cart
P10-1414-8G Hex socket head screw M6x16 $0.99 Out of Stock Add to cart
P10-1414-9A Cross pan head screw M5x10 $0.99 Out of Stock Add to cart
P10-1414-9B Blade $28.99 Out of Stock Add to cart
P10-1414-9C Hex locking nut M12 $0.99 Out of Stock Add to cart
P10-1414-9D Spring washer 10 $0.99 Out of Stock Add to cart
P10-1414-9E Scale $1.99 Out of Stock Add to cart
P10-1414-9F Ratchet handle $1.99 Out of Stock Add to cart
P10-1414-9G Base panel $70.99 Out of Stock Add to cart

Accessories

13-326

Mobility Kit w/Foot Pedal for 10-324*, 10-324TG*, 10-325, 10-326, 10-1414

  *13-324 Mobility Kit Baseplate Adapter is required to use 13-326 Mobility Kit with 10-324 and 10-324TG bandsaws.    		 $119.99 In Stock Add to cart

Features

  • NEW 14” Resaw capacity
  • NEW SP Coated Table
  • NEW Quick Adjust Drift Fence
  • NEW Blade Tension System
  • NEW Blade Guard w/Magnetic Door
  • NEW 2-1/2” & 4” Dust Ports
  • UPDATED Storage Cabinet
  • FASTER SPEEDS – 1,476 / 3,280 ft/min
  • Quick-release blade tension system
  • Large blade tension hand wheel
  • Spring loaded tool-less blade guides
  • Lower wheel dust cleaning brush

Compare



Product Info
Model 10-326: 14" Deluxe Bandsaw

Model 10-326: 14" Deluxe Bandsaw
Model 10-324: 14" Standard Bandsaw

Model 10-324: 14" Standard Bandsaw
Model 10-353: 14" Professional Bandsaw

Model 10-353: 14" Professional Bandsaw
Sku 10-326 10-324 10-353
Motor Horsepower 1-3/4 HP TEFC 1-1/2 HP TEFC 3 HP TEFC
Motor Amps 14/7 14/7 13
Motor Volts 115/230V, 60Hz, 1Ph 115/230V, 60Hz, 1Ph 220V, 60Hz, 1Ph
Blade Speed 1,445/2,950 FT/MIN 1,445/2,950 FT/MIN 4,300 FT/MIN
Cutting Capacity Height 13” 13” 14”
Cutting Capacity Width 13-5/8” 13-5/8” 13-5/8”
Blade Width 3/16” – 3/4” 3/16” – 3/4” 3/16” – 1”
Blade Length 111” 111” 142”
Table Size 21-1/2” x 15-3/4” 21-1/2” x 15-3/4” 21-1/2” x 15-3/4
Table Left Tilt -7° -5° -10°
Table Right Tilt 45° 45° 45°
Table Miter Gauge "T" Slot (2) 3/4” x 3/8” (2) 3/4” x 3/8” (2) 3/4” x 3/8”
Table Height to Floor 40-1/2” 39-1/2” 34-5/8”
Table Height to Base 20-7/8” 20” -
Table Fence Size 18-3/4” x 1-3/4” x 6” 18-3/4” x 1-3/4” x 6” 19-11/16” x 1-3/4" x 6”
Wheel Material Cast Iron Cast Aluminium Cast Iron
Blade Guide Type Spring Loaded Standard Spring Loaded
Table Trunnion Cast Iron Cast Aluminum Cast Iron
Overall Height 74-1/2” 74-1/2” 74-1/2”
Overall Width 33-3/4” 30” 33-1/2”
Overall Depth 25” 25” 28-1/2”
Overall Base Size 24” x 17-5/8” 21-5/8” x 14-3/4” 25-1/4” x 18-1/8”
Dust Port 1@4” 1@4” 2@4”
Overall Net Weight 285 lbs. 218 lbs. 315 lbs.
Warranty 5 Years 5 Years 5 Years

Related products
